Electrochemical Carbon Monoxide (CO) Sensor 0-1000ppm - ME2B-CO

* Low consumption
* High precision
* High sensitivity
* Extensive linear range
* Strong anti-interference ability
* Excellent repeatability and stability

Model Number: ME2B-CO

Quantity:: - +

Inquire Now Add to cart

Mouse over image to zoom

Product Specification

ME2B-CO

Electrochemical Carbon Monoxide Sensor CO Sensor

ME2B-CO electrochemical sensor detects the CO gas concentration by measuring current based on the electrochemical principle, which utilizes the electrochemical oxidation process of target gas on the working electrode inside the electrolytic cell, the current produced in electrochemical reaction of the target gas are in direct proportion with its concentration while following Faraday law, then concentration of CO could be get by measuring value of current

Features:

* Low consumption

* High precision

* High sensitivity

* Extensive linear range

* Strong anti-interference ability

* Excellent repeatability and stability

Application:

Widely use for the domestic application for CO concentration detection.

Items	Technical parameter
Detection Range	0-1000ppm
Max detecting bound	2000ppm
Detecting life	5 years
Sensitivity	5-11 nA/ppm
Resolution	1ppm
Temperature range	-10℃-50℃
Pressure range	Normal atmosphere ±10%
Response time(T90)	<45S
Humidity range	15----%-90%RH
Zero shift(-10℃-+40℃）	≤10ppm
Stability(/Year)	<10%
Load resistance(recommend)	1000Ω
Repeatability	<3% output value
Output linearity	Linearity
